• • Empty weight: 570 kgs
  • Total height: 1,230 mm
  • Total width (with tracks): 720 mm
  • Total length: 1,750 mm
  • Total length (with loaded bucket): 2,640 mm
  • Volume of the bucket: 200 L - Payload 400 kg
  • Lifting angle of the bucket: 70°

  Engine

  • Engine with air cooler
  • Petrol engine
  • Type: monocylinder, 4-stroke 9.5 HP (ype Kohler)
  • Net power: 7 kW
  • Engine size: 277 cc
  • Consumption (fully charged): 2.5 l/h
  • Fuel tank capacity: 7.4 L

  Hydraulic system

  • Hydraulic pump: 3.2 cc double gear pump
  • Professionals hydraulics outlet operating pressure: 160 bars
  • Pump flow: 23 L/mn @ 3 600 rpm
  • Hydraulic traction motor: OMR 200 cc
  • Hydraulic tank capacity: 18 L
  • Original tracks: 150x72x31

  Others

  • Control levers projection protection plate included
  • Electrical ignition included
  • Blade included
  • Footboard included
  • Loading bucket in option
  • Total width (with loaded bucket): 680 mm

• Hydraulic traction motor: OMR 250 cc
• Hydraulic tank capacity: 18 L
• Original tracks: 180x72x43

Others

• Control levers projection protection plate included
• Option electrical ignition included
• Blade included
• Footboard included
• Loading bucket in option
• Total width (with loaded bucket): 750 mm
